Set the parameters p0-20=20, P1-00=3 or 4, single-phase motor mode,

output V, W to connect to a single-phase 220V motor.

Solar panel configuration recommendations:

220V solar inverter input DC 320V-350V, the best working voltage DC320V,

380V solar inverter input DC 540V-580V, the best working voltage DC540V,

The total power of the solar panel is 1.5 times the power of the motor.

A. If you need detailed version of product manual, you can contact us to send it to you free of charge.

B. If there is no paper product manual in the packing case, it is because of product changes or upgrades.

Please contact us for the latest and accurate electronic product manual.

Delivery

A. All package is standard paper box packing or wooden packing for big order.

B. Please note the delivery date using different Express, so please choose the right delivery according to your need.

C. If you prepare to big order ,please contact us if want delivery by any other method.

D. All packages will shipped with a Tracking Number.

Feedback

Your positive feedback is highly appreciated. We guarantee the quality of our products. Each item will be checked carefully before delivery. Please contact us immediately if there is any reason you feel. We will try our best to satisfy you.

If you are satisfied with our products and service, please kindly leave a positive five star (★★★★★) feedback for us. It is very important for us . Thanks very much in advance.

wiring diagram 220V 0.75KW-2.2KW

wiring diagram 220V 4KW

	220V 4KW
Model NO.	WK600D-0040-D1T
Input voltage	DC 280V-380V (best for 300V-320V) or Single phase 220V±10% 50/60Hz
Output voltage	Single phase 220V or Three phase 0-220V 0-650Hz
Power	4KW/5HP
Rated current	16A
Shape size	170*130*160 mm
packing size	225*190*230 mm
Weight	2KG

wiring diagram 220V 5.5KW-7.5KW

SCHEMATIC DIAGRAM

wiring diagram

• Built-in MPPT controller：

MPPT: full name "Maximum Power Point Tracking". It can detect the generation voltage of solar panels in real time, and track the maximum voltage and current value (VI), so that the system can output the driving load with the maximum power and apply it to solar photovoltaic system to coordinate the work between solar panels and loads. It's the brain of photovoltaic systems.

• Supporting Wide Voltage Input;

A, 220V photovoltaic converter corresponding input voltage below 280V will jump low-voltage alarm shutdown, 380V above automatically suppress voltage rise, avoid overlooking overvoltage shutdown;

B, 380V photovoltaic converter corresponding input voltage below 380V will jump low-voltage alarm shutdown, 700V above automatically suppress voltage rise, avoid overlooking overvoltage shutdown.

In the morning, when the illumination intensity rises to a certain extent, the input voltage reaches about 380 V (220 V photovoltaic converter reaches about 280 V), and the photovoltaic converter automatically starts driving load operation without manual operation.

In the evening, when the illumination intensity decreases to a certain extent, the input voltage drops to about 380 V (220 V photovoltaic converter reaches about 280 V), and the photovoltaic converter automatically stops driving the load without manual operation.
