SPECIFICATIONS

Application: Fish Tanks Aquaculture

Battery Included: no

Brand Name: XMSJ

CERTIFICATE: ISO9001/CE

High-concerned chemical: none

Instruction for use: stainless steel rotary drum filter

Manufacturer: Qlozone

Material: Stainless Steel

Max treatment flow: 5m³/h

Name: Koi Drum Filter

Origin: Mainland China

Product name: rotary drum filter

Sewage outlet: 50mm(Custom)

Specification: 5m3/h

Warranty: 12 Months

Water inlet: 50mm(Custom)

Water outlet: 50mm(Custom)

Product Information

Model	QL-PM-5S	QL-PM-10S	QL-PM-30S	QL-PM-60S	QL-PM-80S	QL-PM-100S
Size(mm)	435×305×380	525×335×400	755×550×650	1085×665×780	1225×775×880	1405×775×950
Water Flow	5m3/H	10m3/H	30m³/H	60m³/H	80m³/H	100m³/H
Washing Pump	80W	80W	750W	1000W	1000W	1000W
Reducer power	25W	25W	120W	25W	25W	25W
Working Power	120W	120W	160W	180W	250W	250W
Water inlet	50mm	63mm	63mm*2	110mm*2	110mm*2	200mm*2
Water outlet	50mm	63mm	110mm*2	110mm*2	160mm*2	200mm*2
Sewage outlet	20mm*2	20mm*2	25mm*2	25mm*2	32mm*2	32mm*2



PRODUCT SPECIFICATIONS

Model	QL-PM5	QL-PM10	QL-PM20	QL-PM30
Flow	5T/H	10T/H	15-20T/H	20-30T/H
Inlet	32mm*2	40mm*2	110mm	160mm
Outlet	40mm*2	50mm*2	110mm	160mm
Sewage Outfalls	32mm	32mm	32mm	40mm
Size	430×390×370mm	500×400×430mm	565×465×566mm	800×600×710mm
Backwash pump	86W	86W	86W	750W
