SPECIFICATIONS
Brand Name: NONE
Capacity(L): 24;52;91
Controller: PID
Heating Mode: Four sides heating
High-concerned chemical: none
Origin: Mainland China
Power: 800W;1400W;2000W
Shelves(Standard): 2/4;2/6;2/7
Temperature Fluctuation (℃): ±1
Temperature Range (℃): RT+10~250
Temperature Resolution (℃): 0.1
Temperature Sensor: PT100
Type: Vacuum Oven
Vacuum Degree Range: <133Pa
Voltage/Frequency: AC 220/110V, 50/60Hz
brand name: SCITEK
customized support: OEM, ODM
humidity fluctuation: /
material: stainless steel
model number: VO-25D; VO-55D; VO-90D
place of origin: Shandong, China
temperature fluctuation: ±0.1℃
warranty: 3 years
weight: 42kg;67kg;82kg
Vacuum Oven Features:
1. Intelligent PID control system with PT100 sensor and LCD controller, multiple groups of date 3 display on one screen.
2. Double observation glass window, inner is explosion - proof glass, outside is resin protection plate, more safety.
3. Inflatable port, once-forming thermostability silica gel Sealant strip, with good tightness.
4. LCD vacuum gauge, accuracy class 0.5, Mpa, Kpa, bar, Psi, KGF/cm2 five pressure units optional switch.
|
Model
|
|
VO-25D
|
VO-55D
|
VO-90D
|
|
Capacity(L)
|
|
24
|
52
|
91
|
|
Heating Mode
|
|
Four sides heating
|
|
|
|
Size(WxDxH)
|
Internal (mm)
|
300x300x270
|
415x370x340
|
450x450x450
|
|
|
External (mm)
|
480x480x606
|
560x540x680
|
640x590x780
|
|
Temperature
|
Range (℃)
|
RT+10~250
|
|
|
|
|
Fluctuation (℃)
|
±1
|
|
|
|
|
Resolution (℃)
|
0.1
|
|
|
|
|
Sensor
|
PT100
|
|
|
|
Controller
|
|
PID
|
|
|
|
Vacuum Degree Range
|
|
<133Pa
|
|
|
|
Vacuum Nozzle Diameter(mm)
|
|
Φ10
|
|
|
|
Display
|
|
High efinition LCD
|
|
|
|
Timer
|
|
0~9999min (with timing wait function)
|
|
|
|
Material
|
Internal
|
High-quality hairline stainless steel
|
|
|
|
|
External
|
Cold rolled steel electrostatic spraying exterior
|
|
|
|
Shelves(Standard)
|
|
2
|
|
|
|
Safety Device
|
|
Over temperaure visible & audible alarm
|
|
|
|
Electricity
|
Voltage/Frequency
|
AC 220/110V, 50/60Hz
|
|
|
|
|
Consumption (W)
|
800
|
1400
|
2000
|
|
N.W./G.W. (kg)
|
|
42/52
|
67/92
|
82/105
|
|
Shipping Size (WxDxH) (mm)
|
|
590x550x750
|
704x620x814
|
739x700x889
|
|
Optional
|
|
Vacuum pump filter, Silica gel connecting pipe, Vacuum pump
|
|
|
